STPCI2GDY

compatible system-on-chip, -0.3 to 40V, 4.8W, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $53.80~63.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	63.50 / Piece
10 ~ 50 :	58.50 / Piece
50 ~ 100 :	53.80 / Piece

PartNumber:: STPCI2GDY

Brand:: STMicroelectronics - ST | Pack: BGA | D/C: 09+

Availability:: Supply Ability: 300/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Tina's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-15

From Other Seller

Part Number:STPCI2GDY
US $53.80 - 63.50
STPCI2GDY ST

US $53.80 - 63.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

STPCI2GDY is a X86 Core PC compatible system-on-chip for terminals. The STPCI2GDY STPC Atlas integrates a standard 5th generation x86 core along with a powerful UMA graphics/video chipset, support logic including PCI, ISA, Local Bus, USB, EIDE controllers and combines them with standard I/O interfaces to provide a single PC compatible subsystem on a single device, suitable for all kinds of terminal and industrial appliances.

Parametrics

STPCI2GDY absolute maximum ratings: (1) DC Supply Voltage VDDX: -0.3 to 40V; (2) DC Supply Voltage for Core VCORE: -0.3 to 2.7V; (3) Digital Input and Output Voltage VI, VO: -0.3 to VDD +0.3V; (4) 5 Volt Tolerance V5T: -0.3 to 5.5V; (5) ESD Capacity (Human body mode) VESD: 2000V; (6) Storage Temperature TSTG: -40 to +150°C; (7) Operating Temperature TOPER: 0 to +85°C; (8) Maximum Power Dissipation (package) PTOT: 4.8W.

Features

STPCI2GDY features: (1) powerful×86 processor; (2) 64-bit SDRAM UMA controller; (3) graphics controller; (4) video input port; (5) video pipeline; (5) TFT displat controller; (6) PCI2.1 master/slave/arbiter; (7) 16-bit local bus interface; (8) power management unit; (9) watchdog; (10) jtag IEEE1149.1.
