Product Summary

The DS80C400 network microcontroller offers the highest integration available in an 8051 device. Maximum system-clock frequency of the DS80C400 results in a minimum instruction cycle time of 54ns. Applications of the DS80C400 include: Industrial Control/Automation, Environmental Monitoring, Network Sensors, Vending, Home/Office Automation, Data Converters (Serial-to-Ethernet, CAN-to-Ethernet) , Remote Data Collection Equipment and Transaction/Payment Terminals.

Parametrics

DS80C400 absolute maximum ratings: (1) Voltage Range on Any Input Pin Relative to Ground: -0.5 to +5.5V; (2) Voltage Range on Any Output Pin Relative to Ground: -0.5 to (Vcc3 +0.5V) ; (3) Voltage Range on Vcc3 Relative to Ground: -0.5 to +3.6V; (4) Voltage Range on Vcc1 Relative to Ground: -0.3V to +2.0V; (5) Operating Temperature Range: -40 to +85°C; (6) Junction Temperature: +150°C max; (7) Storage Temperature Range: -55 to +160°C.

Features

DS80C400 features: (1) High-Performance Architecture; (2) Multitiered Networking and I/O; (3) Robust ROM Firmware; (4) 10/100 Ethernet Mac; (5) Full-Function CAN 2.0B Controller; (6) Integrated Primary System Logic.

Diagrams

 DS80C400 Circuit
