Product Summary

TDA7440D is a volume tone (bass and treble) balance (Left/Right) processor for quality audio applications in Hi-Fi systems. The AC signal setting of the TDA7440D is obtained by resistor net-works and switches combined with operational amplifiers.

Parametrics

TDA7440D absolute maximum ratings: (1) Operating Supply Voltage Vs: 10.5V; (2) Operating Ambient Temperature Tamb: 0 to 70°C; (3) Storage Temperature Range Tstg: -55 to 150°C.

Features

TDA7440D features: (1) input multiplexer; (2) one stero inputs; (3) treble and bass control in 2.0dB steps; (4) volume control in 1.0dB steps; (5) two speaker attenuators; (6) all function are programmable via serial bus.

Diagrams

TDA7440D Block Diagram
